Injector FAQ
FAQ: What is an Injector’s Static Flow rate?
ERIKC Answer: Manufacturers rate fuel injectors by the maximum amount of fuel that they can flow in a given amount of time at a given pressure. This measurement is known as Static Flow Rate and is normally taken at 100% duty cycle and a fuel pressure of 43.5 PSI.
Example: At 100% duty cycle a 55 pound (lb) injector at 43.5 PSI of fuel pressure will flow 55 pounds per hour.
Injector Flow Rates are expressed in pounds per hour (lb/hr) or cubic centimeter per minute (cc/min). Given the same pressure 1 lb/hr = 10.5 cc/min.
To convert lb/ hr to cc/min, multiply by 10.5
Sometimes injector flow rates are expressed in milliliter per minute (ml/min)
1 ml = 1 cc
Example: a 220 cc injector = 220 ml injector
FAQ: Most injectors fall into two categories: High or Low Impedance
ERIKC Answer: High Impedance.
These have a typical coil resistance of 12 – 16 ohms and are the most commonly used. Drive circuitry for this type of injector is simple and sometimes referred to as a saturated driver circuit.
Low Impedance.
Low Impedance Injectors has normally a coil resistance of 4 ohms or less and is typically found in larger sized or high performance injectors. Driver circuitry for these types is called a Peak - Hold type and is more complex and costs more than the saturated type.
In a Peak - Hold system, the driver circuit allows a high current for a short time to help turn the injector on quickly. The current is then reduced to a lesser value to keep the injector open. Peak current may be 4 amps to open the injector. Once open, the current might be reduced to as little as 0.75 amps.
